ASRock 128M Manuals

ManualLib has 51 documents for the ASRock 128M: 45 user manuals, 2 quick start guides, 2 installation guides, 1 product leaflet. Every file can be read online or downloaded as a PDF for free.

User Manual 45Quick Start Guide 2Installation Guide 2Product Leaflet 1

Key facts

Brand
ASRock
Model
128M
Documents
51
Languages
EN · ZH
Last added
2012-05-02

Start here

ASRock A790GX/128M Motherboard Quick Installation Guide

ASRock A790GX/128M Motherboard Quick Installation Guide

Quick Start Guide 19 pages · 1.3 MB · ZH

This guide introduces the ASRock A790GX/128M ATX motherboard, its supported AMD AM2+/AM2 processors, DDR2 memory modules, and integrated features such as Gigabit LAN, 7.1‑channel audio, and multiple SATA and PCI‑Express slots. It also lists the package contents and provides safety warnings before installation.

The document walks the user through CPU installation, memory installation, and connecting rear‑panel interfaces (PS/2, USB, VGA, DVI, HDMI, SATA, LAN, audio jacks). BIOS features, power‑on procedures, and troubleshooting tips are included to help users complete a proper setup. This manual is written in Chinese.

Read online

ASRock 128M specifications

Form FactorMicro ATX (9.6‑in x 8.6‑in, 24.4 cm x 21.8 cm)
CPU SocketSocket AM2+ / AM2
Supported CPUsAMD Phenom, FX, Athlon 64, Athlon 64 X2, Sempron
ChipsetNorthbridge AMD 780G, Southbridge AMD SB710
Audio CodecVIA VT1708S, 7.1 CH HD Audio
LAN ControllerRealtek RTL8111DL Gigabit LAN
SATA Connectors6 × SATA II 3.0 Gb/s ports (RAID, NCQ, AHCI, Hot‑Plug)
BIOS8 Mb AMI BIOS

Source: ASRock A780GMH/128M Motherboard User Manual

All ASRock 128M documents by type

User Manual 45

Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.

Quick Start Guide 2

The shortest path to a working setup, usually only a few pages.

Installation Guide 2

Mounting, wiring and first power-up. Read it before the hardware goes in.

Product Leaflet 1
Other documents 1

Questions answered in these manuals

What CPU sockets are supported by the ASRock A780GMH/128M motherboard?

The board supports Socket AM2+ and Socket AM2 processors, including AMD Phenom, FX, Athlon 64, Athlon 64 X2 and Sempron CPUs.

From: ASRock A780GMH/128M Motherboard User Manual

How many SATA ports are available on the A780GMH/128M?

The motherboard offers six SATA II 3.0 Gb/s connectors that support RAID, NCQ, AHCI and hot‑plug functions.

From: ASRock A780GMH/128M Motherboard User Manual

Which Windows operating systems are supported by the A780GMH/128M motherboard?

It supports Microsoft Windows XP, XP Media Center, XP 64‑bit, Vista, and Vista 64‑bit.

From: ASRock A780GMH/128M User Manual

How many USB ports are available on the rear panel?

The rear panel provides four USB 2.0 ports.

From: ASRock A780GMH/128M User Manual

What CPU sockets are supported by the ASRock A785GMH/128M motherboard?

The board supports Socket AM2+, AM2 and AM3 processors, covering AMD Phenom, Athlon, and Sempron families.

From: ASRock A785GMH/128M Motherboard User Manual

How many DDR2 memory slots does the motherboard have and what is the maximum memory capacity?

It provides four DDR2 DIMM slots with a maximum system memory capacity of 16 GB.

From: ASRock A785GMH/128M Motherboard User Manual
