This document describes the features and performance of the ASRock Z68 Pro3-M motherboard, provides installation instructions, and includes motherboard specifications.
This manual provides an overview of the ASRock Z68 Pro3-M motherboard, including its Micro ATX form factor, supported Intel 2nd‑generation Core processors, and key features such as dual‑channel DDR3 memory, integrated graphics, and multiple I/O ports. It also explains how to install the board, connect peripherals, and configure BIOS settings for optimal performance.
Additional sections cover detailed specifications, rear‑panel connector descriptions, supported audio and networking functions, and environmental compliance information. Safety precautions for handling static electricity and proper installation are also included. This manual is written in Chinese.
| Form factor | Micro ATX 9.6" x 9.6" (24.4 cm x 24.4 cm) |
|---|---|
| CPU socket | LGA1155, supports 2nd‑gen Intel Core i7/i5/i3 |
| Chipset | Intel Z68 |
| Memory slots | 4 DDR3 DIMM slots, up to 32 GB |
| Supported DDR3 speeds | 2133/1866/1600/1333/1066 MHz (non‑ECC, un‑buffered) |
| Maximum shared graphics memory | 1759 MB |
| Video outputs | D‑Sub, DVI‑D, HDMI, DisplayPort |
| Integrated graphics | Intel HD Graphics 2000/3000, Pixel Shader 4.1, DirectX 10.1 |
| Audio codec | Realtek ALC892 |
| LAN controller | Realtek RTL8111E Gigabit Ethernet |
It has four DDR3 DIMM slots.
Set the Storage Configuration option to AHCI mode in the BIOS.
The board provides D‑Sub, DVI‑D, HDMI, and DisplayPort connectors.
The motherboard supports up to 32 GB of DDR3 memory.
