3M Mini-Clamp II Plug 371 Series Product Leaflet
Product Leaflet 5 pages · 472 KB · EN
The Mini-Clamp II Plug 371 Series is a 2 mm IDC wiremount connector designed for wiring supplied from Europe and North America. It offers easy, quick termination, integrated cable retention, and a rugged latch for field use while saving board space.
The leaflet lists electrical ratings, physical dimensions, temperature range, and ordering codes, and includes extensive RoHS and China RoHS regulatory information for compliance and warranty details.
3M 371 Series specifications
| Body Material | Nylon body, Polycarbonate cover |
|---|---|
| Contact Plating | 100 Å (2.54 µm) Nickel |
| Gold Over‑Plating | 8 µm minimum Gold with lubricant |
| Wire Accommodation | 20‑22 AWG stranded |
All 3M 371 Series documents by type
Product Leaflet 2
Questions answered in these manuals
Is the Mini-Clamp II Plug 371 Series RoHS compliant?
Yes, the product is RoHS compliant according to EU Directive 2002/95/EC.
Is the Mini‑Clamp Plug RoHS compliant?
Yes, the product is RoHS compliant.
Which tools are recommended for terminating the plug?
Termination can be done with common pliers or 3M Scotchlok E‑9BM or E‑9E crimping tools.
