Key facts
- Brand
- Torex
- Model
- USP-8
- Documents
- 3
- Languages
- EN
- Last added
- 2012-03-19
Start here
TOREX USP-8 Manual(2)
User Manual
This document provides packaging information and reference pattern layout dimensions for the USP-8 product. It states that pin #1 is wider than other pins and the side of the pins is made of nickel instead of being gold-plated. The document provides design and manufacturing-related information about the product.
Read onlineTorex USP-8 specifications
| Board dimensions | 40 x 40 mm |
|---|---|
| Copper coverage | 50% |
| Board material | Glass Epoxy (FR-4) |
| Solder type | Lead (Pb) free |
| Cooling method | Natural convection |
All Torex USP-8 documents by type
User Manual 3
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Datasheet 2
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the power dissipation at 25 °C ambient temperature?
The power dissipation is 1200 mW at 25 °C ambient.
What is the maximum junction temperature for board‑mount operation?
The maximum junction temperature is 125 °C.
