Torex QFN-24 Reel Taping Specifications
Product Leaflet 1 pages · 101 KB · ZH
The reel specification sheet describes the physical dimensions and tolerances for the QFN-24 package tape. It lists the overall length (13.0 mm) and width (4.0 mm) with their respective tolerance values.
Two feed orientations are defined: a standard feed with the device oriented to the right, and a reverse feed with the device oriented to the left. Each orientation includes the required direction of feed for the tape handling equipment. This manual is written in Chinese.
All Torex QFN-24 documents by type
Product Leaflet 2
Questions answered in these manuals
What unit are the dimensions expressed in?
All dimensions are expressed in millimetres.
