Key facts
- Brand
- Philips
- Model
- TEA1533AT
- Industry
- Industrial
- Documents
- 2
- Languages
- EN
- Last added
- 2012-07-04
Start here
Philips TEA1533T/TEA1533AT GreenChip II SMPS Control IC Datasheet
Datasheet 24 pages · 125 KB · EN
The document is a datasheet for the Philips GreenChip II SMPS control IC, specifically models TEA1533T and TEA1533AT. These integrated circuits are designed to operate directly from rectified universal mains voltage (70 to 276 V AC) with high integration levels to minimize external components.
Read onlineAll Philips TEA1533AT documents by type
Datasheet 1
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the minimum mains voltage this IC can operate from?
The device supports universal mains supply operation starting at 70 V AC.
From: Philips TEA1533T/TEA1533AT GreenChip II SMPS Control IC Datasheet
How does the IC handle very low load conditions?
It activates a cycle skipping mode when power is below 300 mW at no-load.
From: Philips TEA1533T/TEA1533AT GreenChip II SMPS Control IC Datasheet
