FrSky Taranis X9D Plus 2019/SE 2019 Remote Controller User Manual
This manual covers the FrSky Taranis X9D Plus 2019 and Taranis X9D Plus SE 2019 remote controllers. The 2019 version features a re-designed mainboard, an additional momentary button for launch mode, and the ACCESS communication protocol with spectrum analysis capabilities. The SE 2019 version includes upgraded switches, M9 hall sensor gimbals, and a PARA wireless trainer function compatible with the FrSky Free Link App and AirLink S.
Read onlineFrSky Taranis X9D Plus 2019 specifications
| Model | Taranis X9D Plus 2019 / Taranis X9D Plus SE 2019 |
|---|---|
| Dimensions (L×W×H) | 200 × 194 × 110 mm |
| Weight (without battery) | 670 g (2019) / 700 g (SE 2019) |
| Operating System | OpenTX |
| Channel Count | 24 CH |
| Built‑in RF Module | ISRM‑S‑X9 |
| Operating Voltage | DC 6.5 V ~ 8.4 V |
| Operating Current | 130 mA @ 8.2 V |
| Operating Temperature | -10 °C ~ 60 °C |
| Screen Resolution | 212 × 64 pixels |
| Mini USB Interface | Supports 2S Li‑ion battery balance charging |
| Model Storage Capacity | 60 models (expandable via Micro‑SD) |
| Compatibility | ACCST D16 and ACCESS receivers |
Source: FrSky Taranis X9D Plus 2019/X9D Plus SE 2019 User Manual
All FrSky Taranis X9D Plus 2019 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
How many channels does the X9D Plus 2019 support?
It supports 24 channels.
From: FrSky Taranis X9D Plus 2019/X9D Plus SE 2019 User Manual
What is the operating voltage range for the transmitter?
The operating voltage is DC 6.5 V to 8.4 V.
From: FrSky Taranis X9D Plus 2019/X9D Plus SE 2019 User Manual
What is the battery compartment size?
The battery compartment size is 100*30*26.5mm (L*W*H).
From: FrSky Taranis X9D Plus 2019/SE 2019 Remote Controller User Manual
What type of battery is required for charging?
Only 2S Li-battery without protective circuit can be applied to the balance charging system.
From: FrSky Taranis X9D Plus 2019/SE 2019 Remote Controller User Manual
What battery type is supported for balance charging?
Only 2S Li-Po battery without protective circuit can be applied to the balance charging system.
How do you navigate the menus?
Use the Scroll Button to roll left or right, the MENU button to enter specific menus, and the PAGE button to switch pages.
