This guide describes the FrSky Taranis X9D Plus 2019 and X9D Plus SE 2019 remote‑control transmitters, covering the redesigned hardware, added instant switch, wheel navigation and upgraded MCU. It explains the ACCESS protocol, 24‑channel expansion, high‑speed digital module and new spectrum‑analysis features.
The document includes detailed specifications, a quick‑setup walkthrough, failsafe configuration, range check, charging instructions and how to perform firmware updates via USB or Micro‑SD card. Contact information for FrSky support and the company address are also provided. This manual is written in Chinese.
| Model | Taranis X9D Plus 2019 / Taranis X9D Plus SE 2019 |
|---|---|
| Dimensions (L×W×H) | 200 × 194 × 110 mm |
| Weight (without battery) | 670 g (2019) / 700 g (SE 2019) |
| Operating System | OpenTX |
| Channel Count | 24 CH |
| Built‑in RF Module | ISRM‑S‑X9 |
| Operating Voltage | DC 6.5 V ~ 8.4 V |
| Operating Current | 130 mA @ 8.2 V |
| Operating Temperature | -10 °C ~ 60 °C |
| Screen Resolution | 212 × 64 pixels |
| Mini USB Interface | Supports 2S Li‑ion battery balance charging |
| Model Storage Capacity | 60 models (expandable via Micro‑SD) |
| Compatibility | ACCST D16 and ACCESS receivers |
It supports 24 channels.
The operating voltage is DC 6.5 V to 8.4 V.
Use the specified USB adapter with a charging voltage of 5 V + 0.2 V and a current greater than 2.0 A.
Up to 60 models can be stored, and this can be expanded with a Micro‑SD card.
