FrSky ESC Neuron 40/60/80 User Manual
The FrSky ESC Neuron is a high-performance electronic speed controller featuring a 32-bit micro-processor and a CNC aluminum protective shell. It supports smart telemetry data transmission via Smart Port (S.Port) for voltage, current, RPM, power consumption, and temperature monitoring. The device includes an adjustable SBEC with support for LUA scripting and the FreeLink App. This manual is written in Chinese.
Read onlineFrSky Neuron 40 specifications
| Size (Neuron 40S) | 39*19*11mm |
|---|---|
| PWM Frequency range | 16kHz to 48kHz |
| SBEC Output Voltage | 5~8.4V |
All FrSky Neuron 40 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the minimum and maximum power setting for Rampup Power?
Rampup Power can be set to relative values from 3% to 150%, where 3% is the minimum to start the engine and 150% is the maximum.
Can the SBEC voltage be adjusted?
Yes, the SBEC voltage can be adjusted through LUA (FrOS & OpenTX Supported) or through FreeLink App with Airlink S.
How is the SBEC voltage adjusted?
The SBEC voltage can be adjusted through LUA (supported by FrOS and OpenTX) or via the FreeLink App with Airlink S.
What is the maximum supported speed for Dshot at 16kHz?
The maximum supported speed for Dshot at 16kHz is 420k.
How is the SBEC voltage adjusted?
The SBEC voltage can be adjusted through LUA (FrOS & OpenTX Supported) or through FreeLink App with Airlink S.
What is the function of the jumper cap?
The jumper cap acts as a switch that makes the ESC output power when connected.
