Key facts
- Brand
- FrSky
- Model
- X6R
- Category
- Other Electronics
- Industry
- Electronics
- Documents
- 3
- Languages
- EN
- Last added
- 2023-10-15
Start here
FrSky RX6R 6/24CH Telemetry Receiver User Manual
The FrSky RX6R is a high-precision telemetry receiver featuring 6 PWM outputs with low latency (9ms less than X series) and redundancy capabilities. It supports the ACCESS protocol and includes new features such as Range Check for pre-flight signal verification and Smart Port interfaces for digital transmission.
Read onlineFrSky X6R specifications
| Dimension | 47.42*23.84*14.7mm (L x W x H) |
|---|---|
| Weight | 15.4g |
| Number of Channels | 16CH |
| Operating Voltage Range | 4.0~10V |
| Operating Current | 100mA@5V |
| Operating Range | full range (>1.5km) |
Source: FrSky X6R Receiver User Manual
All FrSky X6R documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
How do I set the failsafe position for the channels?
Bind the receiver and turn on both devices, move the controls to the desired failsafe position, then press the F/S button on the receiver briefly.
What is the operating voltage range for the X6R?
The receiver operates with a voltage range of 4.0 to 10V.
What is the latency of the PWM output in high speed mode?
The latency of PWM output is 9ms less than that of X series receivers.
How does the Range Check feature work?
In Range Check Mode, RF power decreases and range distance drops to about 30 meters for pre-flight verification.
What is the Smart Port (S.Port) interface?
It is a signal wire full duplex digital transmission interface developed by FrSky Electronic Co., Ltd.
Where can I get firmware updates for the G‑RX6?
Check the download section of the FrSky website for the latest firmware and manuals.
