Key facts
- Brand
- Yamaha
- Model
- EL-40
- Industry
- Appliances
- Documents
- 4
- Languages
- EN
- Last added
- 2012-07-02
Start here
Yamaha EL-400 Electone Owner's Manual
This manual provides instructions for the Yamaha EL-400 Electone, an electronic organ combining AWM tone generation technology with digital electronics. It includes information on included items such as a song sheet and floppy disk, and explains that turning the unit off erases panel settings.
The document details safety precautions, including warnings against opening the instrument, exposure to moisture, or using it near other electrical products to prevent interference. It also outlines proper usage of the bench and data saving procedures.
Yamaha EL-40 specifications
| Footswitch Modes | OFF, RHYTHM, and GLIDE |
|---|---|
| Transpose Range | -6 to +6 semitones |
| Pitch Range | 438.8 Hz to 444.5 Hz |
| Disk Format | 3.5-inch microfloppy |
| Max Songs per Disk | 40 songs |
Source: Yamaha Electone EL-40/60/64 Footswitch and Knee Lever Manual
All Yamaha EL-40 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What functions can the left footswitch control?
The left footswitch can be set to control Glide, rhythm stop, rhythm ending, and rhythm Fill In.
From: Yamaha Electone EL-40/60/64 Footswitch and Knee Lever Manual
How do you activate the Sustain effect with the knee lever?
Fold the knee lever down and press it to the right with your knee when you want to have sustain.
From: Yamaha Electone EL-40/60/64 Footswitch and Knee Lever Manual
What is the range for fine adjustment of voice volume?
The range for fine adjustment of the voice volume is from 0 to 24.
How many settings are available for reverb depth?
There are seven settings for reverb depth, ranging from a minimum of 0 to the maximum.
What type of service personnel should perform repairs if the product has been dropped?
Repairs should be performed by a qualified service person or a service representative authorized by Yamaha.
What happens to panel settings when the Electone is turned off?
Turning the Electone off erases all panel settings you have made.
