Yamaha DTX550K Electronic Drum Assembly Manual
This manual provides step-by-step instructions for assembling the standard components of the Yamaha DTX550K electronic drum system. It details how to construct the RS85A Electronic Drum Rack and install associated pads and modules.
The document outlines safety precautions regarding sharp edges, cable management, and stability before beginning assembly. It guides users through unpacking contents, setting up the rack legs and cymbal holders, and attaching specific components like the DTX500 Trigger Module and XP100SD Drum Pad.
All Yamaha DTX550K documents by type
Questions answered in these manuals
What components are included in the standard assembly?
The standard assembly includes the RS85A Electronic Drum Rack, DTP502 Pad Set, DTX500 Trigger Module, and XP100SD 3-zone Drum Pad.
Is a drum mat required before assembly?
Yes, you must lay a drum mat on the floor or use cardboard from included packages to prevent damaging your floor.
What safety precaution is required before assembling the unit?
You must lay a drum mat on the floor, or use the included cardboard to protect the floor.
How far should the pipe ends slide outward during assembly?
The further end of the pipe should slide outward about 7 cm from the joint part.
