Key facts
- Brand
- Yamaha
- Model
- DTX950K
- Documents
- 3
- Languages
- EN
- Last added
- 2012-06-12
Start here
YAMAHA DTX950K Manual(1)
This document is a preliminary data sheet for the Siemens PMB 2331, a general-purpose up-/downconversion Gilbert cell mixer. It features new B6HF bipolar technology with a frequency range up to 2.0 GHz and operates on a supply voltage of 2.7-4.5 V.
The datasheet provides detailed information including functional descriptions, applications such as cellular radio and cordless telephones, pin configurations, circuit diagrams, and electrical characteristics like absolute maximum ratings and operational ranges.
Yamaha DTX950K specifications
| Technology | B6HF bipolar technology |
|---|---|
| Frequency range | up to 2.0 GHz |
| Supply voltage | 2.7-4.5 V |
| Typical current consumption | 1.6mA |
| Operating temperature range | -40°C to +85 °C |
| Absolute maximum supply voltage | 5.5 V |
| Junction temperature max. | 125 °C |
Source: YAMAHA DTX950K Manual(1)
All Yamaha DTX950K documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What are the applications for the PMB 2331?
It is suitable for cellular radio mixers, cordless telephone mixers, UHF transceivers, RF data links, and frequency conversion.
From: YAMAHA DTX950K Manual(1)
Is the PMB 2331 an open collector output?
Yes, both mixer signal outputs (MO and MOX) are described as open collector.
From: YAMAHA DTX950K Manual(1)
What packages are required to assemble the unit?
You need the HXR4LD Rack System, DTP900 Pad Set, DTP902 Pad Set, and DTX900 Drum Trigger Module.
What should be done before assembling the unit?
Lay a drum mat or cardboard on the floor to prevent damaging the floor or scratching surfaces.
How many turns are needed to tighten the clamp bolt on a Tom Pad?
You need to tighten the clamp bolt with five or six turns on each of the three Tom Pads.
From: YAMAHA DTX950K Manual(2)
What should be done with the 2m spiral tube included in the package?
You can cut the 2m spiral tube to any desired length to take up any slack of the cables.
From: YAMAHA DTX950K Manual(2)
