This document is the user manual for Microchip's PICkitTM 2 microcontroller programmer. It introduces the programmer's function, usage and precautions.
The PICkit 2 User Manual provides step‑by‑step instructions for using the low‑cost Microchip PICkit 2 in‑circuit programmer. It explains the hardware layout, required cables, and the programming software needed to program Microchip flash‑based microcontrollers.
The guide also details how to connect the device via its USB Mini‑B port, interpret the status LEDs, update the firmware, and resolve common issues. A hardware schematic and a list of global sales and service locations are included for reference. This manual is written in Chinese.
| Included items | PICkit 2 programmer, USB cable, Starter Kit CD ROM |
|---|---|
| USB connector type | Mini‑B |
The Busy LED (red) shows that the PICkit 2 is processing a function, such as being in programming mode.
No, for production programming you should use the MPLAB PM3 programmer or another tool designed for production environments.
