Start here

Delta ASDA-A2 Servo Drive User Manual

Delta ASDA-A2 Servo Drive User Manual

User Manual 721 pages · 13.1 MB · EN

This manual provides detailed instructions for installing, configuring, and operating the ASDA-A2R series servo drive with ECMA series servo motors. It covers safety precautions, wiring methods, parameter settings, control modes, and troubleshooting procedures. The guide is intended for servo system designers, installers, and maintenance personnel who need to ensure safe and correct operation of the equipment in industrial environments.

The manual includes chapters on inspection, installation, wiring, panel operation, trial runs, tuning, and control modes including position, speed, and torque. It also addresses safety warnings, grounding requirements, and precautions for handling high-voltage components to prevent injury or equipment damage.

Read online

Delta ASDA-A2 specifications

Product TypeHigh-performance Open-type Servo Drive
Motor TypeThree-phase Permanent Magnet Synchronous AC Servo Motor
ProcessorDigital Signal Processor (DSP)

Source: Delta ASDA-A2 Series Servo Drive User Manual

All Delta ASDA-A2 documents by type

User Manual 2

Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.

Installation Guide 2

Mounting, wiring and first power-up. Read it before the hardware goes in.

Questions answered in these manuals

What motors is this servo drive designed to operate?

The ASDA-A2 servo drive is designed to operate three-phase permanent magnet synchronous motors (PMSM).

From: Delta ASDA-A2 Servo Drive User Manual

What is the maximum recommended length for the encoder feedback cable?

The maximum length for the encoder feedback cable is 20 meters.

From: Delta ASDA-A2 Servo Drive User Manual

Who is the target audience for this manual?

The manual is suitable for servo system designers, installation or wiring personnel, commissioning personnel, and maintenance or inspection personnel.

From: Delta ASDA-A2 Series Servo Drive User Manual

What safety precaution is required regarding the motor terminals?

Do not connect three-phase power to the U, V, W motor output terminals, as this will damage the servo motor.

From: Delta ASDA-A2 Series Servo Drive User Manual

What safety precautions should be taken before installing the AC servo drive?

Do not use the product in a potentially explosive environment, install it in a clean and dry location free from corrosive or flammable gases or liquids, ensure proper grounding, and never connect or disconnect power while the drive is energized.

From: Delta ASDA-A2 AC Servo Drive User Manual

What is the recommended maximum length for the command input cable?

The command input cable should not exceed 3 meters in length.

From: Delta ASDA-A2 AC Servo Drive User Manual
