This document provides information on the installation, composition, control functions, parameter descriptions, communication protocols, testing and maintenance of ASDA-A2 series servo drives and ECMA series servo motors.
This manual provides detailed information for the ASDA‑A2 series servo driver, including safety precautions, installation steps, wiring diagrams, parameter settings, and operation instructions. It is intended for technicians and engineers who need to configure, maintain, or troubleshoot the device.
The document also describes the supported operation modes—position, speed, and torque—and lists the functional features of the B, L, M and U series variants, such as E‑CAM, capture, compare, and resonance suppression functions. This manual is written in Chinese.
| Maximum Power (B series) | 400 W |
|---|---|
| Maximum Power (L series) | 750 W |
