Key facts
- Brand
- Delta
- Model
- DN-02
- Industry
- Industrial
- Documents
- 2
- Languages
- ZH
- Last added
- 2011-12-11
Start here
AELTA DN-02 DeviceNet User Manual
User Manual 36 pages · 1.3 MB · ZH
This manual describes the DN-02 communications adapter, which connects DeviceNet and MODBUS networks. It explains how to install the device, configure its IMO address, MAC address, data rate, and use the provided software tools for mapping and control.
The guide also covers LED status indicators, connector pinout, cable length limits for different data rates, and troubleshooting steps for common network issues. This manual is written in Chinese.
All Delta DN-02 documents by type
User Manual 1
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Other documents 1
Questions answered in these manuals
How many IMO addresses does the DN-02 support?
The DN-02 provides up to eight IMO addresses.
What connector does the DN-02 use for DeviceNet communication?
It uses a 5‑pin Phoenix connector with pins for V+, V‑, CAN_H, CAN_L, and shield.
