DELTA C2000 series Manual
This manual provides safety instructions, installation steps, wiring diagrams, and configuration guidance for the Delta VFD007C43A AC motor drive. It covers product dimensions, terminal specifications, digital operator functions, and CANopen/PLC applications.
Additional sections address motor drive selection, accessory options, and detailed troubleshooting advice for corrosion, dust, wiring, and I/O issues. This manual is written in Chinese.
Delta C2000 specifications
| Input Voltage (Normal Duty) | 3‑phase 380‑480 V 50/60 Hz |
|---|---|
| Output Voltage (Normal Duty) | 3‑phase 380‑480 V |
| Power Rating (Normal Duty) | 2.4 kVA / 1 HP |
| Frequency Range (Normal Duty) | 0‑600 Hz |
| Maximum Wire Gauge (Main Circuit) | 14 AWG (2.1 mm²) |
| Enclosure Protection | IP?? (unspecified) |
Source: DELTA C2000 series Manual
All Delta C2000 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
Which wire size should be used for the main circuit terminals of the VFD007C43A?
The manual specifies 14 AWG (2.1 mm²) copper wire for the main circuit connections of the VFD007C43A model.
How can corrosion damage to the drive be prevented?
Install the drive in a dedicated cabinet, keep liquids away, and perform regular cleaning to avoid corrosion of internal components.
How are the input terminals labeled?
Input terminals are labeled R/L1, S/L2, and T/L3.
From: Delta C2000 Series Variable Frequency Drive User Manual
How are the output terminals labeled?
Output terminals are labeled U/T1, V/T2, and W/T3.
From: Delta C2000 Series Variable Frequency Drive User Manual
