Delta CP2000 Series Manuals

ManualLib has 3 documents for the Delta CP2000 Series (Motor): 3 user manuals. Every file can be read online or downloaded as a PDF for free.

User Manual 3

Key facts

Brand
Delta
Model
CP2000 Series
Category
Motor
Industry
Industrial
Documents
3
Languages
EN · ZH
Last added
2026-10-23

Start here

Delta CP2000 Series Fan/Pump Vector Control Drive User Manual

Delta CP2000 Series Fan/Pump Vector Control Drive User Manual

User Manual 676 pages · 30.1 MB · EN

This manual provides comprehensive instructions for the Delta CP2000 Series Fan/Pump Vector Control Drive. It covers essential topics including receiving and inspecting the unit, installation safety precautions, unpacking procedures, and detailed wiring guidelines for main and control terminals. The document also explains optional accessories and option cards compatible with the drive.

Read online

Delta CP2000 Series specifications

Applicable Motor Capacity1HP(0.75kW)~536HP(400kW)
Input Voltage (230V)230V, 3 phase
Input Voltage (460V)460V, 4E: 4 60V, (EMI filter built-in)
Frame A Screw Torque8 ~10kg-cm(6.9-8.7 lb -in.)

Source: Delta CP2000 Series Fan/Pump Vector Control Drive User Manual

All Delta CP2000 Series documents by type

Questions answered in these manuals

What are the safety precautions before wiring?

AC input power must be disconnected before any wiring to the AC motor drive is made.

From: Delta CP2000 Series Fan/Pump Vector Control Drive User Manual

How should the drive be grounded?

The AC motor drive must be properly grounded using the ground terminal to ensure safety and reduce electromagnetic radiation.

From: Delta CP2000 Series Fan/Pump Vector Control Drive User Manual

Can qualified personnel install the drive?

Yes, only qualified persons are allowed to install, wire, and maintain the AC motor drives.

From: Delta CP2000 Series Intelligent Sensorless Vector Control Drive User Manual

What safety measure must be taken before wiring the AC motor drive?

AC input power must be disconnected before any wiring is made to the drive.

From: Delta CP2000 Series Intelligent Sensorless Vector Control Drive User Manual

What safety measures are required before wiring the AC motor drive?

AC input power must be disconnected before any wiring is made, and anti-static measures should be taken before touching internal components.

From: Delta CP2000 Series Intelligent Sensorless Vector Control Drive User Manual

How often should a stored driver be charged?

It is recommended to charge the driver stored in no charge condition every 2 years for 3~4 hours.

From: Delta CP2000 Series Intelligent Sensorless Vector Control Drive User Manual
