Yamaha PSR-S550 Digital Workstation Owner's Manual
This document serves as the Owner's Manual for the Yamaha PSR-S550 Digital Workstation. It provides essential safety information regarding power supply usage, battery handling, and potential hearing damage from high volume levels.
The manual includes regulatory compliance notices such as FCC Information for U.S.A. users and specific instructions for connecting plugs in the United Kingdom. It also advises owners to record their model number and serial number found on the product's name plate.
Yamaha S55 specifications
| Woofer Size | 16 cm (6.5") Cone |
|---|---|
| Tweeter Size | 2.5 cm (1") Horn |
| Enclosure Type | Bass reflex |
| Frequency Range | 60 Hz—40 kHz |
| Nominal Impedance | 6 Ohms |
| Sensitivity | 90 dB SPL (1watt, 1m) |
| Power Capacity (Noise) | 70 watts |
| Power Capacity (PGM) | 140 watts |
| Max Power | 250 watts |
| Crossover Frequency | 2.5 kHz |
| Protection Circuit Type | Automatic return type |
| Connector Type | Push terminal |
| Dimensions | 370 x 250 x 215 mm |
| Weight | 6 kg |
All Yamaha S55 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
- Yamaha S55 Speaker System Operation Manual 6 p
- Yamaha PSR-S550 Digital Workstation Owner's Manual 142 p
- Yamaha PSR-S550 Digital Workstation User Manual 140 p
- Yamaha DS55 Digital Synthesizer Operation Manual 39 p
- Yamaha YST-MS55D Powered Multimedia Speakers Owner's Manual 15 p
- Yamaha NS-777/NS-555 Speaker System Owner's Manual 6 p
- Yamaha NS-55/NS-45 Home Cinema Main Speaker User Manual 2 p
- Yamaha DVD-S550 DVD Player Owner's Manual 36 p
- Yamaha DV-S5550 DVD Player Owner's Manual 27 p
- Yamaha NS-55/NS-45 Home Cinema Main Speaker Owner's Manual 2 p
- Yamaha FP6110A/DS550U Owner's Manual 2 p
- Yamaha PS-35/PS-55 PortaTone User Manual 36 p
Questions answered in these manuals
How do I connect the speaker cables to the amplifier?
Connect the red input terminal on the system to the output terminal (+) on the power amplifier, and the black output terminal to the output (-).
What is the nominal impedance of the speaker system?
The nominal impedance of the speaker system is 6 Ohms.
What is the model number of this digital workstation?
The model number for this product is PSR-S550.
Where can I find the name plate on the unit?
You will find the name plate located on the bottom of the product.
What is the product name?
The product is the Yamaha PSR-S550.
What type of device is this?
It is a Digital Workstation.
