Yamaha EM-85 Integrated Mixer Instruction Manual
The Yamaha EM-85 is an integrated mixer featuring built-in analog delay line capabilities. It includes multiple input channels with volume, bass, and treble controls, as well as auxiliary and phono inputs. The device is designed to drive speaker outputs directly or provide line-level outputs for recording.
Read onlineYamaha M-85 specifications
| Maximum Output Power | 70 watts into 4 ohms, or 45 watts into 8 ohms |
|---|---|
| Delay Time | 100 to 200 milliseconds |
| Power Consumption | 120 watts (US & Canadian models) |
| Dimensions | 16-1/8"W x 9-1/2"D x 8-3/4"H |
All Yamaha M-85 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Disassembly, diagnostics and part numbers, for repair.
Questions answered in these manuals
What is the delay time range for the built-in analog delay line?
The delay time can be continuously varied from 100 to 200 milliseconds.
What type of fuse should be used for US & Canadian models?
A 3 amp 250 volts type fuse should be used.
What happens when the PROTECTION indicator lights during normal play?
Disconnect the plug from the AC outlet immediately, as your speaker connections may be faulty.
What is the minimum impedance for one speaker pair connected to terminals A, B, or C?
The minimum impedance is 4 ohms per speaker.
