Key facts
- Brand
- Yamaha
- Model
- RS70
- Industry
- Appliances
- Documents
- 5
- Languages
- IT · ZH-CN · EN
- Last added
- 2012-07-03
Start here
Yamaha RS500/RS700 Electronic Drum Rack Owner's Manual
This document is the English, German, French, Chinese, and Japanese owner's manual for the Yamaha RS500 and RS700 Electronic Drum Racks. It serves as a guide for users to safely assemble the product.
The text includes specific safety warnings regarding potential injury from sharp edges, falling components, and improper use of bolts. It details step-by-step assembly procedures for both the RS500 and RS700 models, including instructions on positioning legs, mounting cymbal stands, and attaching tom holders. This manual is written in Chinese.
Yamaha RS70 specifications
| Grid Resolution Range | 15 (128th-notes) to 160 (8th-note triplets) |
|---|---|
| Measure Hold Settings | ON, OFF |
| Distance Parameter Range | -32 ~ +31 |
| Filter Type Options | BYPASS, LPF24D, LPF18, LPF12, HPF24D, BPF12D, BEF12, LPF24A, LPF18s, LPF6, HPF12, BPFw, BPF6, BEF6, Dual LPF, Dual HPF, Dual BPF, Dual BEF, LPF+BPF |
All Yamaha RS70 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What items are included in the RS70 package?
The package includes one complete RS70 group, ten cable ties, and this assembly manual.
What items are included in the RS85 package?
The package includes one complete RS85 group, two rubber feet, six cable ties, and this assembly manual.
What are the standard dimensions and weight of the RS500/RS700 drum rack?
The rack measures 1196mm wide, 528.3mm deep, and 812.3mm high, and weighs 11kg.
From: Yamaha RS500/RS700 Electronic Drum Rack Owner's Manual
What cleaning agents should not be used on the drum rack?
You should not use gasoline, thinners, or alcohol to clean the product.
From: Yamaha RS500/RS700 Electronic Drum Rack Owner's Manual
What are the standard dimensions and weight of the RS500/RS700 drum rack?
The standard assembled unit measures 1196 mm wide, 528.3 mm deep, and 812.3 mm high, and weighs 11 kg.
From: Yamaha RS500/RS700 Electronic Drum Rack Owner's Manual
What cleaning agents should not be used on the drum rack?
Do not use gasoline, thinners, or alcohol, as they may cause fading or deformation.
From: Yamaha RS500/RS700 Electronic Drum Rack Owner's Manual
