Key facts
- Brand
- Yamaha
- Model
- DD-5
- Category
- Other Electronics
- Industry
- Electronics
- Documents
- 5
- Languages
- ZH · EN
- Last added
- 2012-07-02
Start here
Yamaha DD-55 Electronic Drum Kit User Manual
This manual explains how to set up the Yamaha DD-55, including power options, battery installation, and safety precautions. It covers the front and side panel controls, MIDI connections, and how to use the demo song and other functions.
Additional sections describe troubleshooting, specifications, and contact information for Yamaha distributors worldwide. The document also includes warnings about battery handling, FCC compliance, and proper use to avoid hearing loss.
Yamaha DD-5 specifications
| Battery Type | six 1.5V SUM-2 (AM-2), R-14 (LR-14), "C" size |
|---|---|
| Power Adaptor Models | PA-1/PA-1B/PA-3/PA-4/PA-40 |
| Included Accessories | percussion sticks |
All Yamaha DD-5 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What batteries are required to power the DD-55C drum kit?
The kit requires six 1.5V 'C' size batteries, R14P (LR14), or equivalent batteries.
What is the average lifespan of the batteries inside the drum kit?
The internal battery typically has an average lifespan of 5 years.
What type of batteries are required?
The kit requires four 1.5V "C" size batteries (R14P/LR14) or equivalent.
How do I connect the kit to a computer?
Connect the MIDI cable from the DD-55C's MIDI OUT jack to the computer's MIDI IN port.
What type of batteries does the DD-5 require?
The instrument requires six 1.5V SUM-2 (AM-2), R-14 (LR-14), "C" size or equivalent batteries.
Which power adaptors are compatible with the DD-5?
Only the PA-1, PA-1B, PA-3, PA-4, or PA-40 models are usable for household current.
