Key facts
- Brand
- Yamaha
- Model
- C-80
- Documents
- 6
- Languages
- EN
- Last added
- 2012-07-03
Start here
Yamaha MC803/MC1203/MC1603/MC2403 Mixing Console Operation Manual
This manual provides operating instructions for the Yamaha MC-series mixing consoles, available in 8, 12, 16, or 24-channel configurations. The consoles feature electronically balanced inputs, stereo outputs, and a versatile 3-band equalizer with sweepable mid-frequency EQ on each input channel.
The document details the functions of the front panel controls, including input channel settings, master control sections, and various switches for monitoring and routing. It also covers rear panel connectors, application examples, and general specifications for the equipment.
Yamaha C-80 specifications
| Wow & Flutter | Ultra-low |
|---|---|
| Pitch Control Range | +3% |
| Meter Range | -40dB to +6dB |
| Peak Indicator Green | -3dB or more |
| Peak Indicator Red | +4dB or over |
All Yamaha C-80 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
- Yamaha TC-800GL Stereo Cassette Deck User Manual 27 p
- Yamaha NS-C80 Center Speaker System User Manual 2 p
- Yamaha C-80 Stereo Amplifier User Manual 10 p
- Yamaha CDC-805 Compact Disc Player User Manual 20 p
- YAMAHA MC802/1202/1602 Manual 16 p
- Yamaha MC803/MC1203/MC1603/MC2403 Mixing Console Operation Manual 61 p
Questions answered in these manuals
Is a clicking sound when turning on the power normal?
Yes, hearing a click sound when the power switch is turned on is perfectly normal and does not indicate a defect.
How often should tapes be fully wound?
Tapes should be fully wound in the opposite direction at least once every three months to protect the mechanism.
What type of speaker is the NS-C80?
It is an acoustic-suspension type, magnetic-shielding type center speaker system.
How should the NS-C80 be placed?
The speaker should be stabilized with its wide surface down and not placed where it will be exposed to direct sunlight or excessive humidity.
Which turntable input supports MC cartridges?
The PHONO 1 turntable can carry either an MM or an MC cartridge.
What is the impedance requirement for the PHONO 2 input?
It requires an MM cartridge with 47k ohms and 220 pf impedance.
