Yamaha 305D/315D Electone User Manual
This manual introduces the Yamaha 305D and 315D Electone instruments, guiding new owners through initial care instructions and familiarization with the instrument's unique features. It emphasizes proper handling to ensure optimal performance and longevity of the electronic organ.
The document details the operation of key components including the upper and lower keyboards, bass pedals, tone levers, and special preset functions. It explains how to adjust settings for attack, decay, vibrato, and various tonal blends such as symphonic chorus and auto rhythm sections.
Yamaha 315D specifications
| Upper Keyboard Keys | 44 keys (3-2/3 octaves) |
|---|---|
| Lower Keyboard Keys | 44 keys (3-2/3 octaves) |
| Pedal Keys | 13 keys (1 octave) |
All Yamaha 315D documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
How do I adjust the angle of the footboard?
Loosen the Footboard Angle Adjustment Bolt with the supplied key wrench, adjust the angle, and then tighten the bolt to secure it.
How do I adjust the spring tension on the pedal?
Loosen the spring tension locking bolt, rotate the locking nut and spring tension adjustment nut to adjust the tension, and then tighten the locking bolt and nut.
How many sounds can be produced simultaneously on the keyboards?
A maximum of seven sounds may be produced on both the upper and lower keyboard at one time.
What is the precedence rule when multiple bass pedals are pressed?
Only one sound may be produced at a time with the bass pedals, giving precedence to the higher note.
