Delta CP2000 Series Intelligent Sensorless Vector Control Drive User Manual

About this manual

The Delta CP2000 Series is an intelligent sensorless vector control drive designed for AC motor applications. This user manual provides comprehensive guidance on receiving, inspecting, and installing the unit safely. It details critical safety precautions regarding high voltage capacitors and static electricity protection before any wiring or maintenance work begins.

The document serves as a complete operational guide, covering unpacking procedures, main circuit and control terminal wiring diagrams, and optional accessories. It includes detailed instructions for using the digital keypad to configure parameters, along with summaries of parameter settings and descriptions for various application controls.

What's inside

• Introduction
• Installation
• Unpacking
• Wiring
• Main Circuit Terminals
• Control Terminals
• Digital Keypad
• Summary of Parameters
• Fault Codes and Descriptions
• CANopen Overview

Specifications

Frequently asked questions

Can qualified personnel install the drive?

Yes, only qualified persons are allowed to install, wire, and maintain the AC motor drives.

What safety measure must be taken before wiring the AC motor drive?

AC input power must be disconnected before any wiring is made to the drive.

How should the RFI jumper be handled if the drive is supplied from an isolated power system?

The RFI jumper must be cut off to disconnect filter capacitors from ground.

What is the required screw torque for Frame A through C models?

The screws should be tightened to a torque of 8 ~10kg-cm.
