Axis 215 PTZ Network Camera User Manual
The Axis 215 PTZ is a compact IP network camera with 12× optical zoom, 4× digital zoom (48× total), Auto‑Flip and E‑Flip functions, and automatic day/night conversion with a removable IR filter. It supports both Motion JPEG and MPEG‑4 video streams and offers two‑way audio detection and alarm capabilities.
This manual covers the camera’s hardware specifications, PTZ operation, security and network management features, optional accessories, installation guidelines, and software tools such as Axis Camera Station and VAPIX API for integration. It also details power requirements, environmental limits, and troubleshooting procedures. This manual is written in Chinese.
AXIS 215 PTZ specifications
| Optical Zoom | 12× |
|---|---|
| Digital Zoom | 4× |
| Total Zoom | 48× |
| Image Sensor | 1/4" Sony interlaced CCD |
| Focal Length | 3.8‑46 mm |
| Horizontal Angle of View | 4.4°‑51.6° |
| Minimum Illumination (Color) | 1 lux (F1.6) |
| Minimum Illumination (B/W) | 0.3 lux (F1.6) |
| Horizontal Rotation Speed | 180°/sec |
| Vertical Rotation Speed | 140°/sec |
| Video Compression | Motion JPEG, MPEG‑4 Part 2 |
| Maximum Resolution | 704×480 (NTSC), 704×576 (PAL) |
| Power Consumption | 12 V DC ±5%, up to 14.5 W |
| Dimensions (without cover) | 128 × 153 × 131 mm |
| Weight (incl. hard ceiling cover) | 730 g |
All AXIS 215 PTZ documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What video formats does the Axis 215 PTZ support?
The camera supports both Motion JPEG and MPEG‑4 Part 2 video streams.
How many preset positions are available for PTZ control?
The camera provides 20 programmable preset positions.
