Start here
Axis P5532/P5534 PTZ Dome Network Camera User Manual
This manual provides detailed instructions for installing, configuring, and operating the Axis P5532 and P5534 PTZ dome network cameras. It includes guidance on network setup, accessing the camera via browsers or the Internet, and using the Live View page and PTZ controls.
The document also covers advanced features such as Guard Tour, Gatekeeper, audio streaming, storage options, and technical specifications. Safety notices, warranty information, and support contacts are included for administrators and end‑users.
AXIS P5532 specifications
| Image sensor (P5532) | 1/4” Progressive scan CCD |
|---|---|
| Image sensor (P5534) | 1/3” Progressive scan CCD |
| Optical zoom (P5532) | 29x optical zoom |
| Optical zoom (P5534) | 18x optical zoom |
| Minimum illumination (color, P5532) | 0.5 lux at 30 IRE F1.4 |
| Minimum illumination (color, P5534) | 0.74 lux at 30 IRE F1.6 |
| Video compression | H.264 (MPEG‑4 Part 10/AVC, Baseline profile) |
| Power over Ethernet | High Power over Ethernet IEEE 802.3at |
| IP rating | IP51‑rated metal casing |
Source: Axis P5532/P5534 PTZ Dome Network Camera User Manual
All AXIS P5532 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Mounting, wiring and first power-up. Read it before the hardware goes in.
Questions answered in these manuals
How many preset positions does the camera support?
The camera supports up to 100 preset positions for PTZ control.
What type of battery does the Axis P5532/P5534 use?
It uses a 3.0 V CR2032 Lithium battery for the internal real‑time clock.
From: Axis P5532/P5534 PTZ Dome Network Camera Installation Guide
Can the camera be installed outdoors?
Yes, but only in an approved outdoor housing as specified by Axis.
From: Axis P5532/P5534 PTZ Dome Network Camera Installation Guide
What is the optical zoom capability of the AXIS P5532?
The camera provides 29× optical zoom.
Does the AXIS P5532 support Power over Ethernet?
Yes, it supports High Power PoE (IEEE 802.3at) up to 30 W.
