Start here
Axis 214 PTZ Network Camera User Manual
The Axis 214 PTZ is a fully‑featured PTZ network camera designed for security surveillance and remote monitoring. It offers 18× optical zoom, day/night operation, two‑way audio, and extensive networking and security features.
This manual covers installation, network configuration, video and image settings, PTZ control, security options, maintenance procedures, and technical specifications, helping administrators and users get the most out of the camera.
AXIS 214 PTZ specifications
| Image sensor | ¼" Sony Exview HAD CCD |
|---|---|
| Lens focal length | 4.1‑73.8 mm |
| Optical zoom | 18× optical |
| Minimum illumination (color) | 0.3 lux at F1.4, 30IRE |
| Minimum illumination (B/W) | 0.005 lux at F1.4, 30IRE |
| Pan range | ±170° |
| Tilt range | -30° to +90° |
| Maximum pan speed | 100°/sec |
| Maximum tilt speed | 90°/sec |
| Video compression formats | Motion JPEG and MPEG‑4 |
All AXIS 214 PTZ documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Mounting, wiring and first power-up. Read it before the hardware goes in.
Questions answered in these manuals
How many preset positions does the Axis 214 PTZ support?
The camera supports up to 20 preset positions.
What battery powers the internal real‑time clock?
A 3.0 V CR2032 lithium battery powers the RTC.
What is the default IP address of the Axis 214?
The default IP address is 192.168.0.90.
How can I set the IP address of the Axis 214?
You can set the IP address using AXIS IP Utility, UPnP, DHCP, Bonjour, or manually via ARP/Ping commands.
What video compression formats does the Axis 214 PTZ support?
It supports both M‑JPEG and MPEG‑4 Part 2 video streams.
How many users can access the camera simultaneously?
Up to 20 users can access the camera at the same time; when using multicast, the number of users is unlimited.
