Start here
Atmel AT91SAM9260 User Manual
This manual describes the AT91SAM9260 microcontroller, which integrates an ARM926EJ‑S processor with a rich set of peripherals such as Ethernet, USB, ADC, and image‑sensor interfaces. It is intended for hardware designers and firmware developers who need comprehensive data on the device’s architecture, pin configuration, and programming resources.
The document includes sections on features, block diagrams, package options, signal descriptions, reset and test circuitry, peripheral modules (SPI, USART, TWI, etc.), electrical and mechanical characteristics, as well as ordering information and errata. Each chapter provides the necessary details to design, debug, and validate systems based on the AT91SAM9260.
Atmel AT91SAM9260 specifications
| Processor Core | ARM926EJ‑S with Thumb, DSP extensions, Jazelle |
|---|---|
| Maximum Performance | 200 MIPS at 180 MHz |
| External Memory Support | SDRAM, static memory, ECC‑enabled NAND Flash, CompactFlash |
| Ethernet | 10/100 Base‑T MAC |
Source: Atmel AT91SAM9260 Handbook
All Atmel AT91SAM9260 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What processor core does the AT91SAM9260 use?
It incorporates an ARM926EJ‑S ARM Thumb processor with DSP instruction extensions and Jazelle technology for Java acceleration.
Which external memory types are supported by the AT91SAM9260?
The device supports SDRAM, static memory, ECC‑enabled NAND Flash, and CompactFlash.
What processor core does the AT91SAM9260 use?
It incorporates the ARM926EJ‑S ARM Thumb processor.
What are the core power‑supply voltage ranges for the AT91SAM9260?
The core supplies operate from 1.65 V to 1.95 V (VDDBU, VDDCORE, VDDPLL).
