Start here
Atmel AVR32 EVK1100 Getting Started Guide
The AVR32 EVK1100 is a development board that runs a pre‑loaded Control Panel application for logging sensor and actuator data. The Control Panel can be accessed locally via USART or USB and remotely through its built‑in web server.
The guide walks you through powering the board, setting a static IP address on a PC, connecting the Ethernet cable, and opening the Control Panel web page to view sensor data and control actuators.
Atmel AVR32 specifications
| Power supply voltage | 8 V to 20 V |
|---|---|
| Power connector | 5.5 mm × 2.1 mm DC plug |
| Power switch setting | EXT (external supply) |
| LCD status indicator | Lights up when running |
| Default IP address | 192.168.0.2 |
| Example static IP address | 192.168.0.56 |
| Network cable type | UTP Patch 1.5 m Cat.5E |
All Atmel AVR32 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
The shortest path to a working setup, usually only a few pages.
Questions answered in these manuals
How do I power up the AVR32 EVK1100?
Connect the supplied 5.5 mm × 2.1 mm DC power cable to a 8‑20 V source and set the board’s power switch to EXT.
What IP address should I assign to my PC to connect to the EVK1100?
Configure the PC with a static IP such as 192.168.0.56 and a subnet mask of 255.255.255.0; the EVK1100’s default address is 192.168.0.2.
What is the clock speed of the AT32AP7200?
The AT32AP7200 runs at 200 MHz.
