Key facts
- Brand
- Yamaha
- Model
- R-1000
- Documents
- 2
- Languages
- EN
- Last added
- 2012-06-13
Start here
Yamaha R-1000 Stereo Receiver Owner's Manual
This document is the owner's manual for the Yamaha R-1000 AM/FM stereo receiver. It provides essential safety warnings regarding moisture, ventilation, and power sources before operating the appliance.
The guide details how to connect speakers, turntables, tape decks, and antennas to the rear panel of the unit. It also explains the functions of front and rear controls, including volume, tone, and various input selectors.
Yamaha R-1000 specifications
| Dynamic Range | 75dB |
|---|---|
| Reverberation Time (Mode 1) | 1.5 sec |
| Reverberation Time (Mode 4) | 2.4 sec |
| Dimensions | 480 x 45 x 311.5 mm |
| Weight | 4.8 kg |
All Yamaha R-1000 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What are the four reverb time settings?
The unit offers four reverb time settings: 1.5, 1.6, 2.3, and 2.4 seconds.
Can I use a foot switch?
Yes, the unit has a foot switch terminal for remote operation of bypass on/off switching.
What is the maximum power consumption allowed for components connected to the AC outlets on the rear panel?
The switched power supply can support other components with a combined power consumption of up to 200 W.
