Start here
Samsung SCC-C6405P / SCC-641P / SCC-643AP Camcorder User Manual
The SCC‑C6405P series is a 1/4‑inch wide‑dynamic CCD camcorder with 22× optical zoom, 10× digital zoom and 360°/200° pan‑tilt capability. It offers low‑light performance down to 0.007 Lux in color and 0.002 Lux in black‑white, 128 programmable preset points, and privacy‑masking zones.
The device supports RS‑485/RS‑422 remote control, up to 256 cameras can be networked, and it provides multiple alarm inputs/outputs, video composite output, and a power supply of AC 24 V (≈18 W). This manual is written in Chinese.
Samsung SCC-643AP specifications
| Image sensor | 1/4 inch Super HAD CCD |
|---|---|
| Horizontal resolution | 480 lines |
| Optical zoom | 22× |
| Digital zoom | 10× |
| Maximum horizontal rotation speed | 400°/s |
| Maximum vertical rotation speed | 200°/s |
| Number of preset points | 128 |
| Privacy mask areas | 8 |
| Minimum illumination (color) | 0.007 LUX |
| Power supply | AC 24 V, 1.5 A, ~18 W |
Source: Samsung SCC-C6405P / SCC-641P / SCC-643AP Fast Ball Camcorder User Manual
All Samsung SCC-643AP documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the maximum horizontal rotation speed of the camcorder?
The camera can rotate horizontally up to 400 degrees per second.
From: Samsung SCC-C6405P / SCC-641P / SCC-643AP Fast Ball Camcorder User Manual
How many preset positions can be stored?
Up to 128 preset points can be saved.
From: Samsung SCC-C6405P / SCC-641P / SCC-643AP Fast Ball Camcorder User Manual
What is the minimum illumination required for color imaging?
The camcorder can capture color images in as low as 0.007 Lux.
From: Samsung SCC-C6405P / SCC-641P / SCC-643AP Camcorder User Manual
How many preset positions can be stored?
Up to 128 preset points can be programmed.
From: Samsung SCC-C6405P / SCC-641P / SCC-643AP Camcorder User Manual
