Key facts
- Brand
- Samsung
- Model
- U100
- Category
- Digital cameras
- Documents
- 2
- Languages
- EN · ZH
- Last added
- 2012-06-07
Start here
samsung HMX-U10BP/U100BP HMX-U10RP/U100RP HMX-U10EP/U100EP HMX-U10UP/U100UP HMX-U10SP/U100SP digital video camera user manual
This manual introduces the Samsung HMX-U10/U100 digital video camera, highlighting its 10‑megapixel CMOS sensor, full HD 1080p video recording, and lightweight design (0.6" thick, 2.2" wide). It explains key features such as touch navigation, scene modes, high‑speed recording at 120 fps, and built‑in editing software for easy uploading to YouTube.
The guide also covers important safety precautions, proper power handling, environmental warnings, and instructions for protecting recorded data by copying files to a computer. Regulatory information, including RoHS compliance and hazardous substance details, is provided at the end of the document. This manual is written in Chinese.
Samsung U100 specifications
| Power Supply Voltage | KM68V1000B family: 3.0~3.6V; KM68U1000B family: 2.7~3.3V |
|---|---|
| Low Data Retention Voltage | 2V (Min) |
| Package Type | 32-SOP, 32-TSOP1-0820F/R |
| Operating Temperature Range | Commercial: 0~70°C; Extended: -25~85°C; Industrial: -40~85°C |
| Standby Current (TTL) | 0.3 mA |
| Read Cycle Time | 70ns to 100ns |
| Write Cycle Time | 70ns to 100ns |
| Data Retention Voltage | 2.0V to 3.6V |
Source: Samsung KM68V1000B KM68U1000B Family CMOS SRAM Datasheet
All Samsung U100 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the operating voltage range for the KM68V1000B family?
The KM68V1000B family operates between 3.0V and 3.6V.
From: Samsung KM68V1000B KM68U1000B Family CMOS SRAM Datasheet
What is the data retention voltage for these devices?
The low data retention voltage is 2V minimum.
From: Samsung KM68V1000B KM68U1000B Family CMOS SRAM Datasheet
What is the sensor resolution of the camera?
The camera uses a 10‑megapixel CMOS sensor.
What is the highest video resolution supported?
It records full HD video at 1920 × 1080 30 p.
