Key facts
- Brand
- Samsung
- Model
- 510M
- Category
- Monitor
- Industry
- Electronics
- Documents
- 4
- Languages
- ZH
- Last added
- 2012-04-01
Start here
Samsung GT-B5510 User Manual
This manual guides you through installing the GT‑B5510, including inserting the SIM/USIM card, battery placement, and connecting accessories. It also covers basic device functions such as powering on/off, using the touch screen, and navigating the Android‑based interface.
Additional sections explain connectivity options (Bluetooth, WLAN, GPS), how to use built‑in applications (phone, messaging, camera, music, and internet), and important safety and regulatory information, including cleaning and handling precautions. This manual is written in Chinese.
Samsung 510M specifications
| Print speed (A4) | 24 ppm (25 ppm Letter) |
|---|---|
| Resolution | 1200 × 600 dpi (ML‑2510) / 1200 × 1200 dpi (ML‑2570, ML‑2571N) |
| Warm‑up time | < 15 seconds |
| First‑page time | 9 seconds |
| Average power consumption | 390 W (ML‑2510) / 400 W (ML‑2570, ML‑2571N) |
| Energy‑saving mode power | ≤ 6.5 W (ML‑2510) / ≤ 8.5 W (ML‑2570, ML‑2571N) |
| Noise level (standby / printing) | ≤ 35 dBA (standby) / ≤ 53 dBA (printing) |
| Toner cartridge life | ≈ 3 000 pages (5 % coverage) |
| Monthly duty cycle | up to 10 000 pages |
| Weight | 8.9 kg (printer only) |
| Dimensions (W × D × H) | 13.9 × 11.7 × 9.7 in (354 × 297 × 246 mm) |
| Operating temperature | 10 °C – 32 °C (50 °F – 90 °F) |
| Operating humidity | 20 % – 80 % RH |
| Memory | 8 MB (ML‑2510) / 32 MB (ML‑2570, ML‑2571N) |
All Samsung 510M documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Disassembly, diagnostics and part numbers, for repair.
Questions answered in these manuals
What safety precautions should I follow when cleaning the phone?
Use a soft cloth or cotton swab to clean the device and battery contacts; do not use chemicals, cleaners, or abrasive materials.
What is the maximum print speed for the ML‑2510 and ML‑2570 series?
The printers can print up to 24 pages per minute on A4 paper (25 ppm on Letter size).
Which network interfaces are supported?
All three models have a 10/100 Base‑TX Ethernet port; the ML‑2571N includes a built‑in network interface, while the ML‑2510 and ML‑2570 require an optional external wired network interface server.
What safety precautions must be taken before repairing the printer?
Repairs must be performed by qualified personnel, the printer must be unplugged, avoid water or chemicals, and follow all listed safety warnings such as not modifying the machine and using proper voltage.
From: samsung laser PrinterML-1700 series ML-1510 ML-1710 ML-1750 repair manual
How can I run a self‑test on the printer?
After powering on, press the test‑print button for about 1–3 seconds to start the self‑test.
From: samsung laser PrinterML-1700 series ML-1510 ML-1710 ML-1750 repair manual
