GIGABYTE GA-D525TUD / GA-D425TUD Motherboard User Manual
This manual provides detailed information about the GIGABYTE GA-D525TUD and GA-D425TUD motherboards, including supported CPUs, chipset features, memory options, and integrated peripherals. It also includes step‑by‑step BIOS configuration instructions and safety compliance details.
The document contains tables of specifications, diagrams of connectors, and troubleshooting tips for end users and system builders. All sections are organized to help quickly locate setup procedures, hardware limits, and warranty information.
GIGABYTE GA-D525TUD / GA-D425TUD specifications
| Supported CPU | Intel Dual‑core Atom D525 / Intel Single‑core Atom D425 |
|---|---|
| Chipset | Intel NM10 |
| Memory Type | DDR3 800 MHz |
| SATA Ports | 2 × SATA 3 Gb/s |
| USB Ports | 8 × USB 2.0/1.1 |
| LAN | Realtek GbE Ethernet |
| PCI Express Bus | PCI Express (100 MHz) |
Source: GIGABYTE GA-D525TUD / GA-D425TUD Motherboard User Manual
All GIGABYTE GA-D525TUD / GA-D425TUD documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
Which Intel Atom processors are supported by the GA-D525TUD and GA-D425TUD motherboards?
The boards support Intel Dual‑core Atom D525 and Intel Single‑core Atom D425 processors.
From: GIGABYTE GA-D525TUD / GA-D425TUD Motherboard User Manual
How many USB ports does the motherboard provide?
The motherboard includes eight USB 2.0/1.1 ports.
From: GIGABYTE GA-D525TUD / GA-D425TUD Motherboard User Manual
