Key facts
- Brand
- Gigabyte
- Model
- t600
- Category
- Cell Phones
- Documents
- 6
- Languages
- EN · NL · ZH
- Last added
- 2012-05-07
Start here
Gigabyte GSmart t600 User Manual
This manual introduces the GSmart t600 smartphone, covering safety precautions, basic usage, and configuration of wireless and connectivity features. It also lists the device’s specifications such as SAR values and supported network bands.
The document includes detailed instructions for installing applications, managing memory, using email and messaging services, and performing routine maintenance. A comprehensive FAQ section addresses common issues like power problems, standby mode, and ActiveSync synchronization. This manual is written in Chinese.
Gigabyte t600 specifications
| CPU Socket | Socket A |
|---|---|
| Supported CPUs | AMD Athlon, Athlon XP, Duron (K7) |
| Chipset | North Bridge VIA KT600, South Bridge VIA VT8237 |
| Memory Slots | 3 DDR 184‑pin sockets |
| Maximum Memory | Up to 3.0 GB DDR |
| DDR Voltage | 2.5 V DDR DIMM |
| AGP Slot | 1 slot, 8X/4X, 1.5 V |
| PCI Slots | 5 PCI slots |
| SATA Ports | 2 Serial ATA ports |
| LAN | VIA VT6103L, 1 RJ45 port |
| Audio Codec | Realtek ALC655 |
| USB Ports | 8 USB 2.0/1.1 ports |
| Form Factor | ATX, 30.5 cm x 20.0 cm, 4‑layer PCB |
All Gigabyte t600 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Mounting, wiring and first power-up. Read it before the hardware goes in.
Questions answered in these manuals
What BIOS features allow overclocking on this motherboard?
The BIOS provides Over Voltage settings for CPU, AGP, DDR and PCI, as well as Over Clock options for the same components.
How many USB ports are available on the 7VT600P‑RZ motherboard?
The board includes eight USB 2.0/1.1 ports.
What CPU socket does the GA-7VT600-L use?
It uses a Socket A compatible with AMD Athlon XP, Athlon and Duron processors.
How many USB 2.0 ports are provided on the board?
The motherboard includes six USB 2.0 ports built into the VT8237 southbridge.
How many USB 2.0 ports does the GA-7VT600 1394 provide?
The motherboard provides eight USB 2.0 ports.
What chipset is used on the GA-7VT600 1394?
It uses a VIA KT600 northbridge and a VIA 8237 southbridge.
