Start here
Gigabyte GA-8S648FX-775 Motherboard User Manual
This manual guides users through the hardware installation, BIOS setup, driver installation and troubleshooting of the Gigabyte GA-8S648FX-775 motherboard. It includes safety notices, regulatory compliance information and contact details for global support.
The document is organized into chapters covering hardware installation, CPU and heatsink mounting, memory and expansion card installation, BIOS features, power management, and software utilities such as EasyTune and Xpress Recovery. Each section provides step‑by‑step instructions and reference tables. This manual is written in Chinese.
Gigabyte GA-8S648FX specifications
| CPU Socket | Socket 478 |
|---|---|
| Supported CPUs | Intel® Pentium® 4 (Northwood, 0.13 µm) with HT Technology |
| Chipset | SiS 648 / SiS 648FX |
| Memory Types | DDR400 / DDR333 / DDR266 DIMM (2‑channel, up to 3 GB) |
| AGP Slot | AGP 8X/4X (3.3 V) |
| PCI Slots | 5 PCI 2.2 compliant slots (33 MHz) |
| USB Ports | USB 2.0/1.1 (2 ports on board, up to 4 via headers) |
Source: GA-8SG800/GA-8S648FX P4 Titans series main-board chinese installation Manual
All Gigabyte GA-8S648FX documents by type
Mounting, wiring and first power-up. Read it before the hardware goes in.
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
Which Intel processors are compatible with this motherboard?
The board supports Intel® Pentium® 4 processors (Northwood, 0.13 µm) with Hyper‑Threading technology.
From: GA-8SG800/GA-8S648FX P4 Titans series main-board chinese installation Manual
What types of DDR memory can be installed?
It accepts DDR400, DDR333 and DDR266 DIMM modules, up to a total of 3 GB.
From: GA-8SG800/GA-8S648FX P4 Titans series main-board chinese installation Manual
How do I install the CPU on the GA-8S648FX-775 motherboard?
Refer to chapter 1‑3‑1 "CPU Installation" for step‑by‑step instructions on mounting the processor into the LGA775 socket.
Where can I find the BIOS update method?
The BIOS update procedure is described in the section titled "BIOS 更新方法介绍" near the end of the manual.
