Cisco Catalyst 4500 Supervisor Engine II-Plus User Manual
This manual describes the Cisco Catalyst 4500 Supervisor Engine II-Plus, a management engine designed for medium‑size enterprises and branch offices. It outlines the hardware architecture, supported chassis, and the high‑performance switching and routing capabilities that enable integrated data, voice, and video networking.
The document also covers redundancy options, QoS and traffic management features, security functions, software requirements, hardware specifications, ordering information, regulatory compliance, and support resources. It is intended for network administrators and engineers who need to install, configure, and maintain the Supervisor Engine II-Plus. This manual is written in Chinese.
Cisco Catalyst 4500 specifications
| Switching capacity | 320 Gbps |
|---|---|
| Per‑slot capacity | 24 Gbps |
| Throughput | 250 Mpps |
| CPU | 1.3 GHz |
| SDRAM | 512 MB (upgradeable to 1 GB) |
| QoS hardware entries | 64,000 |
| IPv6 routing entries | 128,000 |
