Schneider Altivar 61 Simplified Manual
This simplified manual provides safety warnings, handling instructions, and step‑by‑step procedures for installing, wiring, and configuring the Altivar 61 variable speed drive. It covers preliminary recommendations, mounting of the drive and its DC inductance or transformers, wiring diagrams, and menu configuration.
The guide also details fault diagnosis, recommended maintenance intervals, and protective measures such as power‑removal functions and IP protection ratings. All work must be performed by qualified personnel following the described safety precautions. This manual is written in French.
Schneider ALTIVAR61 specifications
| Power range (Altivar61) | 90‑800 kW |
|---|---|
| Power range (Altivar71) | 90‑630 kW |
| Size (W × H × D) | 340 × 1190 × 377 mm |
| Weight (excluding packaging) | 114 kg |
Source: Schneider Electric Altivar61/71 End-of-Life Instruction Manual
