This document is an installation manual for ATV61 variable speed drives. It introduces the features and installation methods of the drives.
This installation manual provides step‑by‑step instructions for receiving, inspecting, mounting, and wiring the Schneider Altivar 61 variable speed drive. It includes safety warnings, preliminary recommendations, and detailed wiring diagrams for power, control, and optional terminals.
The document also covers mechanical dimensions, weight information, installation of DC chokes or transformers, derating guidelines, EMC requirements, and procedures for operating the drive on IT or corner‑grounded systems. All work must be performed by qualified personnel following the safety symbols and warnings throughout the guide.
| Drive series | Altivar 61 (ATV61) |
|---|
Handle and store the device in its packaging, ensuring that ambient conditions are acceptable.
