Key facts
- Brand
- Cypress
- Model
- 18-MBIT
- Industry
- Industrial
- Documents
- 2
- Languages
- EN
- Last added
- 2012-06-12
Start here
CYPRESS CY7C1381D CY7C1381F CY7C1383D CY7C1383F 18-Mbit (512K x 36/1M x 18) Flow-Through SRAM handbook
Datasheet 29 pages · 961 KB · EN
This document describes the CY7C1381D, CY7C1381F, CY7C1383D, and CY7C1383F synchronous flow-through SRAMs. These devices are designed to interface with high-speed microprocessors with minimum glue logic.
Read onlineCypress 18-MBIT specifications
| Maximum Access Time (133 MHz) | 6.5 ns |
|---|---|
| Maximum Operating Current (133 MHz) | 210 mA |
| Core Power Supply Voltage | 3.3V |
All Cypress 18-MBIT documents by type
Datasheet 2
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What are the maximum access times for this SRAM?
The maximum access time is 6.5 ns for the 133 MHz version and 8.5 ns for the 100 MHz version.
What voltage supplies are required for this device?
The device requires a +3.3V core power supply and operates with either a +2.5V or +3.3V I/O supply.
What is the maximum bus operation speed?
The devices support 250-MHz bus operations with zero wait states.
From: Cypress CY7C1370DV25/CY7C1372DV25 18-Mbit Pipelined SRAM Datasheet
What is the maximum operating current for the 250 MHz device?
The maximum operating current is 350 mA.
From: Cypress CY7C1370DV25/CY7C1372DV25 18-Mbit Pipelined SRAM Datasheet
