CYPRESS SEMICONDUCTOR AN15733 Power Management - RGB Color Mixing Hardware For EZ-Color LED Controllers handbook
This application note (AN15733) explains how to drive multiple high‑power LEDs using Cypress EZ‑Color devices such as the CY8CLED16. It covers temperature‑feedback and color‑sensor feedback loops, constant‑current driver topologies, and practical design considerations for the CY3261A‑RGB demonstration board.
The document includes two PSoC Express example projects that demonstrate LED dimming, color mixing with PrISM blocks, and I²C‑controlled tuning. It also provides a brief appendix of photometry units and author contact information.
Cypress CY8CLED16 specifications
| Regulated LED current | 350 mA |
|---|---|
| Total LED current on board | 1.05 A |
| Typical LED forward voltage | 3.7 V |
| LED output power per channel | 4 W |
All Cypress CY8CLED16 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What current does the LM3402 buck converter regulate for the LEDs?
The LM3402 is set to regulate the LED current to 350 mA.
How many LED controllers are on the CY3261A‑RGB board and what is the total current?
The board has three LED controllers providing a total LED current of 1.05 A.
How many independent LED channels does the CY8CLED16 support?
The CY8CLED16 supports up to 16 independent LED channels.
From: Cypress CY8CLED16 EZ-Color HB LED Controller Preliminary Data Sheet
What is the operating voltage range of the CY8CLED16?
It operates from 3.0 V to 5.25 V, and can run down to 1.0 V using the on‑chip switch‑mode pump.
From: Cypress CY8CLED16 EZ-Color HB LED Controller Preliminary Data Sheet
