ASUS I-AP55T Manuals

ManualLib has 2 documents for the ASUS I-AP55T (Other Electronics): 2 user manuals. Every file can be read online or downloaded as a PDF for free.

User Manual 2

Key facts

Brand
ASUS
Model
I-AP55T
Documents
2
Languages
EN
Last added
2012-04-06

Start here

ASUS P/I-AP55TV All-In-One Pentium Motherboard User's Manual

ASUS P/I-AP55TV All-In-One Pentium Motherboard User's Manual

User Manual 96 pages · EN

The ASUS P/I-AP55TV User's Manual describes the all-in-one Pentium motherboard and its setup. It covers the item checklist, features, installation steps, jumper settings, system memory, CPU, expansion cards, external connectors, and power connection procedures.

It also documents BIOS software and setup, the Desktop Management Interface utility, ATI VGA drivers and utilities for Windows 95, Windows 3.x, Windows NT, IBM OS/2 and OS/2 Warp, plus other video drivers and troubleshooting.

Read online

ASUS I-AP55T specifications

Supported CPU frequencies75, 90, 100, 120, 133, 150 or 166 MHz
ChipsetIntel Triton
Memory module type72‑pin SIMM modules, 4‑32 MB each, up to 128 MB total
Level‑2 cache size256 KB or 512 KB of Pipeline Burst SRAM
PCI Bus Master IDE controller – max IDE devices4 devices
IDE PIO transfer rateup to 17 MB/s
IDE DMA transfer rateup to 22 MB/s
Onboard SCSI controllerSupports optional PCI‑SC200 SCSI card
PCI‑SC200 fixed SCSI ID7
Onboard audioCreative Technology Vibra 16S 16‑bit SoundBlaster compatible

Source: Asus P/I-AP55T Motherboard User Manual

All ASUS I-AP55T documents by type

User Manual 2

Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.

Questions answered in these manuals

What items are included with the ASUS P/I-AP55TV motherboard?

The package includes the motherboard, one IDE ribbon cable, one floppy ribbon cable, support drivers and utilities, readme files, a technical support form, ATI video drivers and utilities, and Creative Labs audio drivers and utilities. Optional items include a pipelined burst cache module, infrared module, and PCI-SC200 Fast-SCSI card.

From: ASUS P/I-AP55TV All-In-One Pentium Motherboard User's Manual

What sections does the ASUS P/I-AP55TV manual cover?

The manual is divided into Introduction, Features, Installation, BIOS Setup, DMI Utility, VGADrivers, and sections for Windows, OS/2, other video drivers, and troubleshooting.

From: ASUS P/I-AP55TV All-In-One Pentium Motherboard User's Manual

What CPUs are supported by the P/I-AP55T motherboard?

It supports Pentium CPUs running at 75 MHz up to 166 MHz in a ZIF Socket 5 or 7.

From: Asus P/I-AP55T Motherboard User Manual

How many IDE devices can be connected and what are the transfer rates?

The onboard PCI Bus Master IDE controller supports up to four IDE devices, with PIO modes up to 17 MB/s and DMA mode 2 up to 22 MB/s.

From: Asus P/I-AP55T Motherboard User Manual
