ASUS P4B-M Motherboard User Manual
User Manual 116 pages · 3.1 MB · EN
This guide walks you through installing the ASUS P4B-M motherboard, including CPU, memory, expansion cards, and power connections. It also explains the BIOS menus, power‑up sequence, and software support on the included support CD.
Safety precautions, connector descriptions, and troubleshooting tips are included to help you avoid damage and ensure reliable operation of the motherboard.
ASUS P4B-M specifications
| USB ports | 5 |
|---|---|
| ZIF socket | present |
| UART2 | available |
All ASUS P4B-M documents by type
User Manual 2
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What should you do before relocating the system?
Disconnect the power cable from the electrical outlet before moving the system.
How many USB ports does the ASUS P4B-MX motherboard have?
The motherboard provides five USB ports.
How many PCI slots does the P4B-M motherboard have?
It provides three 32‑bit PCI slots for expansion cards.
What voltage does the AGP slot support?
The AGP slot is keyed for and supports +1.5 V AGP cards.
