Start here
ASUS P7H55/USB3 Motherboard User Manual
This manual covers the P7H55/USB3 motherboard, describing its components, safety precautions, and step‑by‑step installation procedures. It includes detailed BIOS settings, jumper configurations, power‑management options, and troubleshooting tips.
Additional sections provide contact information for ASUS support, licensing details for GPL/LGPL software, and instructions for obtaining source code. The document is intended for technicians and end‑users assembling or maintaining the motherboard. This manual is written in Chinese.
ASUS USB3 specifications
| Form Factor | Micro ATX |
|---|---|
| Chipset | AMD 880G / AMD SB710 |
| Processor Socket | Socket AM3 |
| Supported Processors | Sempron, Phenom II X3, Athlon II X2, Phenom II X2, Athlon II X4, Athlon II X3, Phenom II X4, Phenom II X6 |
| Memory Type | DDR3 SDRAM, up to 2600 MHz |
| USB Ports | 2 x SuperSpeed USB 3.0, 4 x Hi‑Speed USB, 6 x Hi‑Speed via headers (total 12 USB) |
| LAN | Realtek RTL8111E Gigabit Ethernet |
| Graphics | ATI Radeon HD 4250 (shared video memory) |
| Audio | HD Audio 8‑channel (VIA VT17088) |
| Storage Interfaces | 6 x SATA‑300 (RAID) + 1 x ATA‑133 |
All ASUS USB3 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What processor socket does the ASUS M4A88T-M/USB3 motherboard use?
It uses a Socket AM3 for AMD processors.
How many USB 3.0 ports are provided on the board?
The motherboard includes two SuperSpeed USB 3.0 ports.
How can I update the BIOS on the P7H55/USB3 motherboard?
You can update the BIOS using ASUS Update, EZ Flash 2, or the CrashFree BIOS recovery utility.
Where can I download the source code for the GPL/LGPL software included with the motherboard?
The source code can be downloaded for free from the ASUS support website at http://support.asus.com.
