ASUS system board A7S2666-VM User Guide
This guide covers everything needed to install and operate the ASUS A7S266-VM motherboard, including safety precautions, component descriptions, and BIOS configuration. It also explains how to use ASUS utilities such as EZFLASH, AFLASH, and PC Probe for system monitoring and updates.
The manual includes a specifications summary, detailed connector and slot listings, and troubleshooting tips. Contact information for ASUS support in Asia‑Pacific, America, and Europe is provided for further assistance.
ASUS A7S266-VM specifications
| CPU Socket | Socket A for AMD Athlon XP/Athlon/Duron 2 GHz+ Thoroughbred core CPU ready |
|---|---|
| Chipset | Northbridge: SiS 740, Southbridge: SiS 961B |
| Memory | 2 × DDR DIMM sockets, max 2 GB unbuffered PC2100/1600 non‑ECC DDR SDRAM |
| Expansion Slots | 4 × PCI, 2 × UltraDMA 133/100/66 |
All ASUS A7S266-VM documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What does the ASUS PC Probe utility do?
It monitors temperature, fan speed, voltages, and provides system information such as CPU type and memory usage.
What safety steps should be taken before installing the motherboard?
Before installation, disconnect power, ground yourself, verify all power cables are correctly connected, and consider professional assistance for grounding and handling.
How do I set jumper modes on the motherboard?
Place a jumper cap on the appropriate pins (e.g., pins 1‑2 for Jumper Mode, pins 2‑3 for Jumper Free) as illustrated in the jumper settings diagram.
