Start here
ASUS M2V-X User Guide
This guide introduces the ASUS M2V-X motherboard, its package contents, special features, and hardware layout. It covers CPU installation, memory configuration, expansion slots, and connector details.
The manual also explains power‑up procedures, BIOS setup options, and software utilities such as Cool ‘n’ Quiet!™. Safety notices, FCC/ICES compliance, and troubleshooting advice are included to help users install and operate the system safely.
ASUS M2V specifications
| Chipset | VIA K8M890 |
|---|---|
| Memory | 2 x 240‑pin DIMM sockets, up to 4 GB DDR2 800/667/533 MHz |
| Expansion slots | 1 PCI Express x16, 2 PCI |
| Graphics | Integrated VIA DeltaChrome GPU, up to 256 MB shared memory |
| Storage interfaces | 2 SATA 3.0 Gb/s ports, RAID 0/1/JBOD |
| Audio | Realtek ALC883 6‑channel CODEC |
| LAN | Realtek RTL8100C 10/100 Ethernet |
| USB ports | Up to 8 USB 2.0 ports |
All ASUS M2V documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What safety step should be taken before moving the system?
Disconnect the power cable from the electrical outlet before relocating the system.
How many USB 2.0 ports does the motherboard provide?
It supports up to eight USB 2.0 ports.
What safety step should be taken before relocating the system?
Disconnect the power cable from the electrical outlet before moving the system.
From: ASUS M2V-X User Guide
How do you launch the Cool ‘n’ Quiet!™ software?
Insert the motherboard support CD, install the Cool ‘n’ Quiet!™ software, then select it from the Start menu under ASUS → Cool & Quiet.
From: ASUS M2V-X User Guide
How can I set a BIOS password on the V-Series M2V890?
In the BIOS Setup you can choose the password check mode: set it to [Setup] to require a password only when entering the Setup utility, or set it to [Always] to require a password both at Setup and at system boot.
