Yamaha F12/F12M/F15/F25/F28 Speaker Systems Owner's Manual
This document is the Owner's Manual for Yamaha professional loudspeaker systems, specifically models F12, F12M, F15, F25, and the F28 subwoofer. It provides essential safety precautions regarding heat, humidity, and power-up procedures to prevent damage to equipment and hearing loss.
The manual details connection examples for full-range, bi-amp, and combined subwoofer configurations using Neutrik NL4FC connectors. It also includes specific instructions for hanging the F12 and F15 models, specifying load limits and installation angles.
Yamaha F-15 specifications
| Frequency Range (F12) | 55 Hz to 20 kHz |
|---|---|
| Power Capacity NOISE (F12M) | 700 W (EIA RS-426) |
| Nominal Impedance (F15) | 8 ohms |
| Sensitivity (F25) | 98 dB (W, m) |
| Frequency Range (F28 Subwoofer) | 35 Hz to 2 KHz |
| Max Power Capacity (F28) | 4000 W |
Source: Yamaha F12/F12M/F15/F25/F28 Speaker Systems Owner's Manual
All Yamaha F-15 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
Which models are designed for suspension?
Only the F12 and F15 models are designed for suspension; the F12M, F25, and F28 are not.
From: Yamaha F12/F12M/F15/F25/F28 Speaker Systems Owner's Manual
What is the maximum load when hanging F12/F15 speakers?
The total load must be no greater than 172 kg, including speakers, eye bolts, and wires.
From: Yamaha F12/F12M/F15/F25/F28 Speaker Systems Owner's Manual
