JVC JY‑HD10 Camcorder User Manual
This manual describes the JY‑HD10 high‑definition digital camcorder, its 1.18‑megapixel progressive CCD sensor, 10× optical zoom lens with F1.8‑F1.9 aperture, and optical image stabilization. It also lists supported recording formats such as 720/30p HD, 480/60p SD, DV and MPEG‑2, and explains the bundled editing software.
Connectivity options include i.LINK (IEEE‑1394), USB, XLR audio inputs, and composite/component video outputs. Power can be supplied via a 6.3 V AC adapter or a 7.2 V battery pack, and the camcorder weighs 2.8 lb (body only). The appendix lists supplied accessories and optional cables.
JVC JY-HD10 specifications
| HD recording resolution | 720/30p |
|---|---|
| Image sensor | 1.18 Megapixel Progressive CCD |
| Optical zoom | 10× |
| Lens aperture | F1.8–F1.9 |
| Power source | DC 6.3 V (adapter) / DC 7.2 V (battery) |
| Weight (body only) | 2.8 lb (1,270 g) |
| LCD monitor resolution | 200,000 pixels |
| Audio inputs | 2 XLR |
| i.LINK connector | 4‑pin IEEE‑1394 |
All JVC JY-HD10 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
How many XLR audio inputs are available?
The camcorder provides two XLR audio inputs.
What power sources can be used with the camcorder?
It can be powered by a 6.3 V DC AC adapter or a 7.2 V DC battery pack.
